Feature | Details |
---|---|
Model | TUF GAMING B760M-E D4 |
CPU | Intel® Socket LGA1700 for Intel® Core™ 14th, 13th, & 12th Gen, Pentium® Gold, Celeron® |
Chipset | Intel® B760 Chipset |
Memory | 4 x DIMM slots, Max. 128GB, DDR4 5333(OC) – 2133 MHz, Dual Channel, XMP, OptiMem II |
Graphics | 1 x DisplayPort, 1 x HDMI™ port (Supports 4K@60Hz) |
Expansion Slots | 1 x PCIe 4.0 x16 slot, 1 x PCIe 4.0 x16 slot (x4 mode), 1 x PCIe 4.0 x1 slot |
Storage | 2 x M.2 slots, 4 x SATA 6Gb/s ports |
Ethernet | 1 x Realtek 2.5Gb Ethernet, TUF LANGuard |
Wireless & Bluetooth | Vertical M.2 slot (Key E, CNVi & PCIe) – Module sold separately |
USB | Rear: 2 x USB 3.2 Gen 2, 2 x USB 3.2 Gen 1, 2 x USB 2.0; Front: 1 x USB 3.2 Gen 2 (Type-C), 2 x USB 3.2 Gen 1, 4 x USB 2.0 |
Audio | Realtek 7.1 Surround Sound CODEC, Audio Shield, Premium capacitors, Dedicated PCB layers |
Back Panel I/O Ports | 2 x USB 3.2 Gen 2, 2 x USB 3.2 Gen 1, 2 x USB 2.0, 1 x DisplayPort, 1 x HDMI™ port, 1 x Realtek 2.5Gb Ethernet, 3 x Audio jacks, 1 x PS/2 Keyboard/Mouse combo port, 1 x Vertical M.2 slot (Key E) |
Internal I/O Connectors | 1 x 24-pin Main Power, 1 x 8-pin +12V, 1 x 4-pin +12V, 2 x M.2 slots, 4 x SATA 6Gb/s, 1 x USB 3.2 Gen 2 (Type-C), 1 x USB 3.2 Gen 1 (5G) header, 2 x USB 2.0 headers, 3 x Addressable Gen 2 headers, 1 x AURA RGB header, 1 x Clear CMOS header, 1 x COM Port header, 1 x Front Panel Audio header, 1 x 20-3 pin System Panel header, 1 x S/PDIF Out header |
Special Features | DIGI+ VRM, ESD Guards, TUF LANGuard, Overvoltage Protection, SafeSlot Core+, Stainless-Steel Back I/O, M.2 Q-Latch, Q-DIMM, Q-LED, Q-Slot, Flexible M.2 heatsink, VRM heatsink design, ProCool, SafeDIMM, AURA Sync |
Software | Armoury Crate, AI Suite 3, TUF GAMING CPU-Z, DTS Audio Processing, Norton 360 for Gamers (60 Days Free Trial), WinRAR |
BIOS | 128 Mb Flash ROM, UEFI AMI BIOS |
Manageability | WOL by PME, PXE |
Accessories | 2 x SATA 6Gb/s cables, 1 x I/O Shield, 1 x M.2 Rubber Package, 1 x M.2 SSD screw package, 1 x TUF Gaming sticker, 1 x TUF Certification card, 1 x User guide |
Operating System | Windows® 11, Windows® 10 64-bit |
Form Factor | mATX (24.4 cm x 24.4 cm) |
Intel Motherboards, Motherboards
Asus TUF Gaming B760M-E D4 Micro ATX Motherboard
Availability:
Not Available. Check Counterpart Models. Thank you
- Model: TUF GAMING B760M-E D4
- CPU: LGA1700, Intel Core™ 14th/13th/12th Gen, Pentium® Gold, Celeron®
- Chipset: Intel® B760
- Memory: 4 x DIMM, Max 128GB, DDR4 up to 5333 MHz (OC)
- Graphics: 1 x DisplayPort, 1 x HDMI™ (4K@60Hz)
- Expansion Slots: 1 x PCIe 4.0 x16, 1 x PCIe 4.0 x16 (x4 mode), 1 x PCIe 4.0 x1
- Storage: 2 x M.2 slots, 4 x SATA 6Gb/s
- Ethernet: 1 x Realtek 2.5Gb
- Wireless & Bluetooth: Vertical M.2 slot (Key E, CNVi & PCIe) – Module sold separately
- USB Ports: 6 rear (including 2 x USB 3.2 Gen 2), 7 front (including 1 x USB 3.2 Gen 2 Type-C)
- Audio: Realtek 7.1 Surround Sound CODEC
- Back I/O: 2 x USB 3.2 Gen 2, 2 x USB 3.2 Gen 1, 2 x USB 2.0, 1 x DisplayPort, 1 x HDMI™, 1 x Realtek 2.5Gb Ethernet, 3 x Audio jacks, 1 x PS/2 combo port
- Special Features: DIGI+ VRM, TUF LANGuard, SafeSlot Core+, M.2 Q-Latch, AURA Sync
- Software: Armoury Crate, AI Suite 3, TUF GAMING CPU-Z, Norton 360 for Gamers (60 Days Trial)
- BIOS: 128 Mb Flash ROM, UEFI AMI
- Form Factor: mATX (24.4 cm x 24.4 cm)
₱8,750.00 ₱8,940.00
Not Available. Check Counterpart Models. Thank you
