PROLiNK SFC series is a single-phase input/ single-phase output Line-Interactive UPS system with PROLiNK’s latest Super-Fast Charging technology. This cutting-edge technology is able to recharge the battery back to 90% of its capacity within 2-4 hours, and is ideal for providing stable backup power to home/ small office applications. A wide input voltage range is supported due to the integrated 3-Step AVR which features 2 boosts and 1 buck to regulate output voltage. This prevents under voltage brownouts and over voltage surges. The unit also comes with universal sockets to provide better compatibility with a wider range of devices.

Capacity: 1200VA
INPUT
Nominal Voltage: 230VAC
Voltage Range: 140 – 300 VAC ± 5%
Nominal Frequency: 50 or 60Hz (Auto sensing)
OUTPUT
Voltage Regulation: ± 10%
Frequency: 50 or 60Hz ± 1Hz
Transfer Time (typical): 2 – 6ms
Waveform: Simulated Sinewave
BATTERY
Number of Battery: 12 V/8.2 Ah x 2
Recharge Time (typical): 2-4 hours recover to 90% capacity
ALARM & INDICATORS
LED Display: AC Mode – Green Lighting Battery Mode
Sounding: Battery Mode – Sounding every 10 seconds Low Battery

• Built-in super fast charger, battery can be recharged to 90% of its capacity within 2-4 hours
• Excellent microprocessor control guarantees high reliability
• Boost and buck AVR for voltage stabilization
• Auto restart while AC is recovering
• Simulated sine wave
• Off-mode charging
• Cold start function
• RJ11 ports (Fax/Modem Protection)
• Optional USB communication port
• Optional HID Compliant USB (for PRO851SFCU)

• Off Mode Charging
• Type: Sealed Lead Maintenance Free
• Power Rating: 1000
• Voltage Range: 140-290v
• Frequency: 50/60hz+ 5%
• Voltage(inverted mode): 20V+10%
• Capacity: 50/60hz+ 1%
• Transfer Time
• Over/Under Voltage: Transfer to battery mode
• Over load/short Circuit: Current Limit for both Mains and Battery modes

• UPS battery 12v9ah(6-FM-9)
• Capacity : 12v9AH
• for use : UPS
• Self-Discharge : 91%

• TRUE AVR (Automatic Voltage Regulation)
• Wide Input Voltage Range 140 ~ 300VAC
• Load Auto Sensing and Abnormal Protection
• Super-Fast Charging technology recharges battery to 90% within 2-4 hours
• Surge Protection to protect connected equipment against disruptive power surges
• Excellent microprocessor control guarantees High Reliability.
• Full protection for Short-Circuit, Overload, Over-Discharge,Over-Charge and Over-Temperature
• Boost and buck AVR for voltage stabilization
• 2x Universal Socket to provide better compatibility with a wider range of devices
• Synology supported

SUPER FAST CHARGING – Battery can be recharged to 90% of its capacity within 2-4 hours.
SURGE PROTECTION – PROVIDES SURGE PROTECTION FOR YOUR EQUIPMENT – Provides protection for the connected equipment from incoming spikes, surges, etc. Extra assurance while keeping your network safe from disruptive power surges.
ADVANCE EARLY WARNING OF UPS SHUTDOWN – AMPLE TIME TO BACKUP YOUR FILES – Immediately alerts you to an output overload, high temperature or low battery condition. Ample time to either correct the condition or shutdown your system before battery time runs out.
OVERLOAD PROTECTION – Initiate the alarm to inform the user in an event of an overload. Automatic shutdown, thus prolonging the lifespan of the UPS.
OVER TEMPERATURE PROTECTION – Shuts the power supply down in the event of unacceptably high internal temperatures.
INTELLIGENT BATTERY MANAGEMENT – BETTER RELIABILITY AND PROTECTION – Additional protection for battery overcharging and deep discharging. Maximizes battery performance, life and reliability through intelligent precision charging.
