Component | Specification |
---|---|
CPU | AMD Socket AM5, support for: AMD Ryzen™ 7000 Series Processors |
Chipset | AMD B650 |
Memory | – Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MT/s memory modules <br> – 4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory <br> – Dual channel memory architecture <br> – Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules <br> – Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules |
Onboard Graphics | – Integrated Graphics Processor <br> – 1 x DisplayPort, supporting a maximum resolution of 3840×2160@144 Hz <br> – 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz <br> – Support for DisplayPort 1.4 version and HDR. <br> – Support for HDMI 2.1 version and HDCP 2.3. <br> – Support native HDMI 2.1 TMDS compatible ports. <br> (Graphics specifications may vary depending on CPU support.) |
Audio | – Realtek® Audio CODEC <br> – High Definition Audio <br> – 2/4/5.1/7.1-channel <br> – You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
LAN | – Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
Wireless Communication module | – AMD Wi-Fi 6E RZ616 (MT7922A22M) (For PCB rev. 1.0/PCB rev. 1.2) <br> – WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands <br> – BLUETOOTH 5.2 <br> – Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate <br> – Intel® Wi-Fi 6E AX210 (For PCB rev. 1.1) <br> – WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands <br> – BLUETOOTH 5.3 <br> – Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate (Actual data rate may vary depending on environment and equipment.) |
Expansion Slots | – CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) <br> – For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. <br> – Chipset: 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2) |
Storage Interface | – CPU: 2 x M.2 connectors (Socket 3, M key, type 25110/2280 support) <br> – M2A_CPU and M2B_CPU connectors support PCIe 4.0 x4/x2 SSD (PCB rev. 1.0/1.1) <br> – M2A_CPU connector supports PCIe 5.0* x4/x2 SSD, M2B_CPU connector supports PCIe 4.0 x4/x2 SSD (PCB rev. 1.2) <br> – Actual support may vary by CPU. <br> – Chipset: 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) (M2C_SB) <br> – 4 x SATA 6Gb/s connectors <br> – RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices <br> – RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
USB | – CPU: 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support <br> – 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel <br> – 1 x USB 3.2 Gen 1 port on the back panel <br> – CPU + USB 2.0 Hub: 3 x USB 2.0/1.1 ports on the back panel <br> – Chipset: 1 x USB Type-C® port with USB 3.2 Gen 2×2 support, available through the internal USB header <br> – 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) <br> – 4 x USB 2.0/1.1 ports available through the internal USB headers |
Internal I/O Connectors | – 1 x 24-pin ATX main power connector <br> – 1 x 8-pin ATX 12V power connector <br> – 1 x 4-pin ATX 12V power connector <br> – 1 x CPU fan header <br> – 1 x water cooling CPU fan header <br> – 2 x system fan headers <br> – 1 x system fan/water cooling pump header <br> – 2 x addressable LED strip headers <br> – 2 x RGB LED strip headers <br> – 1 x CPU cooler LED strip/RGB LED strip header <br> – 3 x M.2 Socket 3 connectors <br> – 4 x SATA 6Gb/s connectors <br> – 1 x front panel header <br> – 1 x front panel audio header <br> – 1 x USB Type-C® header, with USB 3.2 Gen 2×2 support <br> – 1 x USB 3.2 Gen 1 header <br> – 2 x USB 2.0/1.1 headers <br> – 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) <br> – 1 x serial port header <br> – 1 x reset button <br> – 1 x reset jumper <br> – 1 x Clear CMOS jumper |
Back Panel Connectors | – 2 x SMA antenna connectors (2T2R) <br> – 1 x Q-Flash Plus button <br> – 1 x DisplayPort <br> – 1 x HDMI port <br> – 1 x USB Type-C® port, with USB 3.2 Gen 2 support <br> – 1 x USB 3.2 Gen 2 Type-A port (red) <br> – 3 x USB 3.2 Gen 1 ports <br> – 3 x USB 2.0/1.1 ports <br> – 1 x RJ-45 port <br> – 3 x audio jacks |
I/O Controller | iTE® I/O Controller Chip |
H/W Monitoring | – Voltage detection <br> – Temperature detection <br> – Fan speed detection <br> – Water cooling flow rate detection <br> – Fan fail warning <br> – Fan speed control (Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.) |
BIOS | – 1 x 256 Mbit flash <br> – Use of licensed AMI UEFI BIOS <br> – PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
Unique Features | – Support for GIGABYTE Control Center (GCC) <br> – Support for Q-Flash <br> – Support for Q-Flash Plus |
Bundled Software | – Norton® Internet Security (OEM version) <br> – LAN bandwidth management software |
Operating System | – Support for Windows 11 64-bit <br> – Support for Windows 10 64-bit |
Form Factor | ATX Form Factor; 30.5cm x 24.4cm |
Specs may change anytime without further notice*
