Intel Motherboards, Motherboards

Gigabyte Z890M AORUS ELITE WIFI7 ICE Micro ATX LGA1851 White Motherboard

Name: Gigabyte Z890M AORUS ELITE WIFI7 ICE Micro ATX LGA1851 White Motherboard
Brand: Gigabyte
SKU: GA-Z890M-A-ELITE-WF7-ICE
Availability: Domestic or Local Stocks via Bermor Techzone

Availability:

Domestic or Local Stocks via Bermor Techzone

Sold: 1

Key Features

Supports Intel® Core™ Ultra processors (Series 2)
Digital twin 12+1+2 phases VRM solution
D5 Bionic Corsa for Infinite Memory Performance
AORUS AI SNATCH : Auto-Overclocking Software by AI models
AI Perfdrive : Provides optimal and customized BIOS preset profile for users
Premium Compatibility : 4*DDR5 with XMP Memory Module Support
WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation
EZ-Latch Plus : PCIe and M.2 slots with Quick Release & Screwless Design
EZ-Latch Click : M.2 heatsinks with screwless design
Sensor Panel Link : Onboard video port for hassle-free in-chassis panel setup
Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
New Power Monitor in HWinfo for real-time monitoring on CPU power phases
Ultra-Fast Storage : 3*M.2 slots, including 1* PCIe 5.0 x4
Efficient Thermal : VRM Thermal Armor Advanced & M.2 Thermal Guard L
Fast Networking : 2.5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
Extended Connectivity : USB4 Type-C with DP-Alt, DisplayPort
Ultra Durable PCIe Armor : The metal back plate of PCIe x16 slot for enhanced durability
PCIe UD Slot X : PCIe 5.0 x16 slot with 10X strength for graphics card

Estimated Delivery: Jul 22 – Jul 25 (Business Days Only)

₱15,999.00 ~~₱16,490.00~~

Domestic or Local Stocks via Bermor Techzone

Add to WishlistAlready In Wishlist

iBTZ 24/7 Product Assistant

AI Agent

CPU	LGA1851 socket, supports Intel® Core™ Ultra Processors. L3 cache varies with CPU.
Chipset	Intel® Z890 Express Chipset
Memory	– DDR5 8800(O.C)/8600(O.C)/8400(O.C)/etc. MT/s support
	– 4 x DDR5 DIMM sockets, up to 256 GB (64 GB per DIMM)
	– Dual-channel architecture
	– ECC Un-buffered DIMM support (operates in non-ECC mode)
	– Non-ECC Un-buffered DIMM support
	– Extreme Memory Profile (XMP) support
Onboard Graphics	– Intel® HD Graphics Processor
	– 1 x USB4® Type-C® (3840×2160@144 Hz, DP 2.1)
	– 1 x DisplayPort (3840×2160@144 Hz, DP 2.1)
	– 1 x front HDMI (1920×1080@30 Hz, HDMI 1.4)
	– Supports up to 3 displays simultaneously
Audio	– Realtek® Audio CODEC, HD Audio
	– 2/4/5.1/7.1-channel audio
	– S/PDIF Out support
LAN	Realtek® 2.5GbE LAN chip
Wireless	– MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0), Bluetooth 5.4
	– Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.1), Bluetooth 5.4
	(Wi-Fi 7 features require Windows 11 SV3)
Expansion Slots	– CPU: 1 x PCIe 5.0 x16 slot
	– Chipset: 1 x PCIe 4.0 x4 slot
Storage Interface	– CPU: 1 x M.2 (PCIe 5.0 x4/x2 SSD), 1 x M.2 (PCIe 4.0 x4/x2 SSD)
	– Chipset: 1 x M.2 (PCIe 4.0 x4/x2 SSD), 4 x SATA 6Gb/s connectors
	– RAID 0, 1, 5, 10 support for NVMe and SATA
USB	– 1 x USB4® USB Type-C® (DisplayPort)
	– 1 x USB Type-C® (USB 3.2 Gen 2), 1 x USB 3.2 Gen 2 Type-A, 6 x USB 3.2 Gen 1, 8 x USB 2.0
Internal I/O	– 1 x 24-pin ATX main power, 2 x 8-pin ATX 12V
	– 4 x fan headers, 3 x M.2 connectors, 4 x SATA 6Gb/s
	– RGB headers, USB headers, TPM header, Thunderbolt™ add-in card connectors
Back Panel	– 1 x USB4® Type-C®, 1 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1, 4 x USB 2.0/1.1
	– 2 x antenna connectors, 1 x DisplayPort, 1 x RJ-45, 1 x optical S/PDIF Out, 2 x audio jacks
I/O Controller	iTE® I/O Controller Chip
H/W Monitoring	Voltage, temperature, fan speed detection, fan/water cooling flow rate detection
BIOS	1 x 256 Mbit flash, AMI UEFI BIOS
Unique Features	GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup
Operating System	Windows 11 64-bit
Form Factor	Micro ATX, 24.4cm x 24.4cm

Specification may change without further notice.

SKU: GA-Z890M-A-ELITE-WF7-ICE Categories: Intel Motherboards, Motherboards Brand: Gigabyte

Brands	Gigabyte
Intel Chipset	Z890
Form Factor	MATX
RAM Generation	DDR5
CPU Socket	LGA 1851
