Category | Specifications |
---|---|
Unique Feature | – PCIe Gen5 (Graphics, M.2) |
– ASRock Blazing M.2 Gen5 Fan Heatsink | |
– Dual Channel DDR5 | |
Rock-Solid Durability | – Server-Grade Low-Loss PCB |
– 10+2+1 Power Phase, 105A SPS for VCore | |
– Flexible Integrated I/O Shield | |
Ultrafast Gaming | – Killer 2.5G LAN, Killer 802.11ax Wi-Fi 6E Module |
– Killer DoubleShot™ Pro | |
– ASRock Lightning Gaming Ports | |
EZ Update | – ASRock Auto Driver Installer |
CPU | – Supports AMD Socket AM5 Ryzen™ 7000 Series Processors |
Chipset | – AMD B650 |
Memory | – Dual Channel DDR5 Memory Technology |
– 2 x DDR5 DIMM Slots | |
– Supports DDR5 non-ECC, un-buffered memory up to 6800+(OC) | |
– Max. capacity of system memory: 96GB | |
– Supports XMP and EXPO memory modules | |
BIOS | – 256Mb AMI UEFI Legal BIOS with GUI support |
Graphics | – Integrated AMD RDNA™ 2 graphics (Actual support may vary by CPU) |
– 1 x eDP 1.4, supports max. resolution up to Full HD 60Hz | |
– 1 x HDMI 2.1, supports HDR, HDCP 2.3, max. resolution up to 4K 120Hz | |
Audio | – 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec) |
– Impedance Sensing on Rear Out port | |
– Individual PCB Layers for R/L Audio Channel | |
– Nahimic Audio | |
LAN | – 2.5 Gigabit LAN 10/100/1000/2500 Mb/s |
– Killer E3100G | |
– Supports Killer LAN Software | |
– Supports Killer DoubleShot™ Pro | |
Wireless LAN | – 802.11ax Wi-Fi 6E Module |
– Supports IEEE 802.11a/b/g/n/ac/ax | |
– Supports Dual-Band 2×2 160MHz with extended 6GHz band support | |
– Supports Bluetooth 5.3 + High speed class II | |
– Supports MU-MIMO | |
– Supports Killer LAN Software | |
– Supports Killer DoubleShot™ Pro | |
Slots | CPU: |
– 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode* | |
Chipset: | |
– 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module | |
Storage | CPU: |
– 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode* | |
– 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* | |
Chipset: | |
– 2 x SATA3 6.0 Gb/s Connectors | |
RAID | – Supports RAID 0 and RAID 1 for SATA storage devices |
– Supports RAID 0, RAID 1, and RAID 10 for M.2 NVMe storage devices* | |
USB | – 1 x USB 3.2 Gen2x2 Type-C (Front) |
– 1 x USB 3.2 Gen2 Type-C (Rear) | |
– 3 x USB 3.2 Gen2 Type-A (Rear) | |
– 2 x USB 3.2 Gen1 (Front) | |
– 6 x USB 2.0 (4 Rear, 2 Front) | |
Connectors | – Various connectors including eDP Signal, Addressable LED Headers, Fan Connectors, Power Connectors, and more |
Rear Panel I/O | – 2 x Antenna Ports |
– 1 x HDMI Port | |
– 1 x Optical SPDIF Out Port | |
– 3 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (USB32_23 are Lightning Gaming Ports.) | |
– 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) | |
– 4 x USB 2.0 Ports | |
– 1 x RJ-45 LAN Port | |
– 1 x Line Out Jack (Gold Audio Jack) | |
– 1 x Microphone Input Jack (Gold Audio Jack) | |
Software and UEFI | Software: |
– ASRock Motherboard Utility (Phantom Gaming Tuning) | |
– Killer Control Center | |
– ASRock Polychrome SYNC* | |
UEFI: | |
– ASRock Full HD UEFI | |
– ASRock Auto Driver Installer | |
– ASRock Instant Flash | |
Accessories | – User Manual |
– SATA Data Cables | |
– ASRock WiFi 2.4/5/6 GHz Antenna | |
– Screw for M.2 Socket | |
Form Factor | – Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm |
– 10 Layer PCB | |
OS | – Microsoft® Windows® 10 64-bit / 11 64-bit |
Certifications | – FCC, CE |
– ErP/EuP ready (ErP/EuP ready power supply is required) |
Specs may change anytime without further notice*
