Where Durability Meets Gaming Mastery
- The PowerColor RX 7700 XT Fighter is built to last, featuring a reinforced backplate that adds rigidity and durability. Its Copper Base Direct Touch ensures rapid and efficient heat dissipation. Equipped with high-quality Japanese dual ball bearings, this card is designed for longevity and consistent performance.
High Quality Japanese Dual Ball Bearings
- Dual ball bearings reduce rotational friction, providing excellent heat dissipation and effectively doubling the expected lifetime of the fans.
Intelligent Fan Controller
- Utilizing temperature detection from a smart chip, fans will start running when the GPU reaches 60℃ and shut down below 50℃. Efficient cooling, fan-noise reduction, and extended product lifetime are all benefits of a more accurate temperature monitoring.
Copper Base Direct Touch
- A smooth copper base directly contacts the GPU to enhance exceptional heat transfer, and improves heat dissipation from the VRAMs to keep the card in the optimum cooling condition.
|Graphics Engine||RX 7700 XT 12G-F/OC|
|Video Memory||12GB GDDR6|
|Stream Processors||3456 Units|
|Engine Clock (OC)|
|Memory Clock||18.0 Gbps|
|Bus Standard||PCIE 4.0|
|Standard Display Connectors||1 x HDMI 2.1, 3 x DisplayPort 2.1|
|(only 2x simultaneous DP2.1 connections supported)|
|Product Remark||‘Game Clock’ is the expected GPU clock when running|
|typical gaming applications, set to typical TGP|
|(Total Graphics Power). Actual individual game clock|
|results may vary.|
|‘Boost Clock’ is the maximum frequency achievable on|
|the GPU running a bursty workload. Boost clock|
|achievability, frequency, and sustainability will|
|vary based on factors including thermal conditions|
|and variation in applications and workloads.|
|AMD Stream Technology||Support|
|AMD Eyefinity Technology||Support|
|AMD Smart Access Memory||Support|
|Power Specs + Board Dimensions|
|303mm128mm50mm (with bracket)|
|Minimum System Power requirement (W)||750W|
|Extension Power Connector||Two 8-pin PCI Express Power connectors|
