CPU | LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors |
Chipset | Intel® Z790 Express Chipset |
Memory | Support for DDR5 8000(O.C.) /7800(O.C.) /7600(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4400 MT/s memory modules |
2 x DDR5 DIMM sockets supporting up to 96 GB (48 GB single DIMM capacity) of system memory | |
Dual channel memory architecture | |
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) | |
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
Support for Extreme Memory Profile (XMP) memory modules | |
Onboard Graphics | Integrated Graphics Processor-Intel® HD Graphics support: |
1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz | |
* Support for HDMI 2.1 version and HDCP 2.3. | |
** Support native HDMI 2.1 TMDS compatible ports. | |
1 x DisplayPort port, supporting a maximum resolution of 5120×2160@60 Hz | |
* Support for DisplayPort 1.4 version and HDCP 2.3 | |
* The DisplayPort does not support HDMI connection by adapter | |
Audio | Realtek® ALC4080 CODEC |
Support for DTS:X® Ultra | |
High Definition Audio | |
2-channel | |
LAN | Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
Wireless Communication | Intel® Killer™ Wi-Fi 6E AX1690 |
WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands | |
BLUETOOTH 5.3 | |
Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate | |
Expansion Slots | CPU: |
1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 | |
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. | |
Storage Interface | CPU: |
1 x M.2 connector on the back of the GC-Z790I BTB PLUG (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) | |
Chipset: | 1 x M.2 connector on the front of GC-Z790I BTB PLUG (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) |
2 x SATA 6Gb/s connectors | |
RAID 0 and RAID 1 support for NVMe SSD storage devices | |
RAID 0 and RAID 1 support for SATA storage devices | |
USB | Chipset: |
1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2×2 support | |
1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header | |
3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel | |
4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) | |
2 x USB 2.0/1.1 ports on the back panel | |
Chipset+USB 2.0 Hub: | 4 x USB 2.0/1.1 ports available through the USB headers on the front of GC-Z790I BTB PLUG |
Internal I/O Connectors | 1 x 24-pin ATX main power connector |
1 x 8-pin ATX 12V power connector | |
1 x external power connector (Note 1) | |
1 x CPU fan header | |
1 x fan/water cooling pump header | |
2 x system fan headers (SYS_FAN1/SYS_FAN2 (Note 1)) | |
1 x addressable LED strip header (Note 1) | |
1 x RGB LED strip header | |
2 x M.2 Socket 3 connectors (M2A_CPU (Note 2)/M2P_SB (Note 1)) | |
2 x SATA 6Gb/s connectors | |
1 x front panel header | |
1 x front panel audio header (routed from the adapter card on the rear panel) | |
1 x speaker header | |
1 x USB Type-C® header, with USB 3.2 Gen 2 support | |
1 x USB 3.2 Gen 1 header | |
1 x USB 2.0/1.1 header (Note 1) | |
1 x reset button (Note 1) | |
1 x reset jumper | |
1 x Clear CMOS jumper | |
Back Panel Connectors | 2 x SMA antenna connectors (2T2R) |
1 x DisplayPort | |
1 x HDMI port | |
1 x USB Type-C® port, with USB 3.2 Gen 2×2 support | |
3 x USB 3.2 Gen 2 Type-A ports (red) | |
2 x USB 3.2 Gen 1 ports | |
2 x USB 2.0/1.1 ports | |
1 x Q-Flash Plus button | |
1 x RJ-45 port | |
2 x audio jacks | |
I/O Controller | iTE® I/O Controller Chip |
H/W Monitoring | Voltage detection |
Temperature detection | |
Fan speed detection | |
Water cooling flow rate detection | |
Fan fail warning | |
Fan speed control | |
BIOS | 1 x 256 Mbit flash |
Use of licensed AMI UEFI BIOS | |
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
Unique Features | Support for GIGABYTE Control Center (GCC) |
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. | |
Support for Q-Flash | |
Support for Q-Flash Plus | |
Support for Smart Backup | |
Bundled Software | Norton® Internet Security (OEM version) |
LAN bandwidth management software | |
Operating System | Support for Windows 11 64-bit |
Support for Windows 10 64-bit | |
Form Factor | Mini-ITX Form Factor; 17.0cm x 17.0cm |
Specification may change without further notice.
