X670E-PRO WIFI-CS
ASUS Prime series motherboards are expertly engineered to unleash the full potential of the latest AMD Ryzen 7000-series processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME X670E-PRO WIFI-CSM provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features.
The ASUS PRIME X670E-PRO WIFI-CSM offers this all in a sleek, futuristic-looking package centered around a spaceship design aesthetic, with a silver-toned nameplate and chipset cover.
AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors
Chipset
AMD X670
Memory
4 x DIMM, Max. 192GB, DDR5 8000+(OC)/7800(OC)/…
Graphics
1 x DisplayPort, 1 x HDMI® port
Expansion Slots
AMD Ryzen™ 7000 Series Desktop Processors: 1 x PCIe 5.0 x16 slot AMD X670 Chipset: 1 x PCIe 4.0 x16 slot (supports x4 mode), 1 x PCIe 4.0 x4 slot
Storage
Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports
Ethernet
1 x Realtek 2.5Gb Ethernet
Wireless & Bluetooth
Wi-Fi 6E (2×2), Bluetooth v5.2
USB
Rear USB: 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®), 4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C®), 5 x USB 3.2 Gen 1 ports (4 x Type-A + 1 x USB Type-C®) Front USB: 1 x USB 3.2 Gen 2 connector (supports USB Type-C®), 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports, 3 x USB 2.0 headers support additional 6 USB 2.0 ports
Audio
Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC
Back Panel I/O Ports
Various USB ports, DisplayPort, HDMI, Wi-Fi module, Ethernet, Audio jacks, BIOS FlashBack™ button
Internal I/O Connectors
Various headers for fans, power, storage, USB, and more
Miscellaneous
Addressable Gen 2 headers, AURA RGB header, Clear CMOS button, COM Port header, CPU Over Voltage jumper, Front Panel Audio header (AAFP), Power button, SPI TPM header (14-1pin), 20-3 pin System Panel header with Chassis intrude function, Thermal Sensor header, Thunderbolt™ header
Special Features
ASUS 5X PROTECTION III, ASUS Q-Design, ASUS Thermal Solution, ASUS EZ DIY, AURA Sync
Software Features
ASUS Exclusive Software, UEFI BIOS, ASUS EZ DIY, Manageability, Accessories, Operating System
