The AMD RDNA™ 3 Architecture elevated by buffed cooling and power delivery to effortlessly churn out frames at 4K resolution and beyond,
and backed with an arsenal of rugged reinforcements to cover your six.
Lock, load, and dominate with the TUF Gaming Radeon™ RX 7700 XT.
AXIAL-TECH UPGRADES
Air Superiority
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 24% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
NEW DIRECTION
Well-maintained Formation
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 55 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 60 Celsius, referencing a speed curve that balances performance and acoustics for work or play.
2.96-SLOT DESIGN
Phase That Blaze
A generously sized heatsink efficiently soaks up heat from the AMD Radeon™ RX 7700 XT GPU, allowing it to be whisked away by the three Axial-tech fans.
MILITARY-GRADE 20K CAPACITORS
Resilient Squadron
A lineup of capacitors rated to last 20,000 hours at 105 Celsius brings higher temperature and ripple tolerance to the GPU power rail, arming the card for long-term deployment in challenging conditions.
Specification | Value |
---|---|
Model | TUF-RX7700XT-O12G-GAMING |
Graphic Engine | AMD Radeon™ RX 7700 XT |
Bus Standard | PCI Express 4.0 |
OpenGL | OpenGL® 4.6 |
Video Memory | 12GB GDDR6 |
Engine Clock | OC mode: up to TBD MHz (Boost Clock)/up to TBD MHz (Game Clock) |
Default mode: up to TBD MHz (Boost Clock)/up to TBD MHz (Game Clock) | |
Stream Processors | 3456 |
Memory Speed | 18 Gbps |
Memory Interface | 192-bit |
Resolution | Digital Max Resolution 7680 x 4320 |
Interface | Yes x 1 (Native HDMI 2.1) |
Yes x 3 (Native DisplayPort 2.1) | |
HDCP Support | Yes (2.3) |
Maximum Display Support | 4 |
NVlink/Crossfire Support | No |
Accessories | 1 x TUF certificate of Reliability |
1 x TUF Gaming Graphics Card Holder | |
1 x TUF Velcro Hook & Loop | |
1 x Collection card | |
1 x Thank you card | |
1 x Speedsetup Manual | |
Software | ASUS GPU Tweak III & Drivers: download from support site |
Dimensions | 319.8 x 150.9 x 59.2 mm |
12.6 x 5.94 x 2.33 inch | |
Recommended PSU | 750W |
Power Connectors | 2 x 8-pin |
Slot | 2.96 Slot |
AURA SYNC | ARGB |
