Linksys Atlas 6 Dual-Band Whole Mesh WiFi 6 System

• Game Band – Tri-Band structure provides a 4.8 Gbps Game Band exclusive for your gaming rigs and bings pure immersion.
• Game Accelerator – Detect and optimize gaming streams, to ensure your gaming stays immersive.
• Game Statistics – Real-time latency, game duration and network resource allocation in a glance with fine-tuned UI.
• Game Protector – Keep your accounts and documents safe with Homecare™ security system.
• Expansive Coverage – 8 antennas, Beamforming, high-power FEM, 4T4R combine to deliver WiFi coverage up to a 4-bedroom house.
• 2.5 Gbps Wired Connection – Unleash the potential of your next-level bandwidth network with a 2.5 Gbps WAN/LAN port. ✔ Powerful Processing – 1.5 GHz Quad-Core CPU ensure your network performance always at peak run.
• Easy Setup – Sset it up in minutes with the powerful Tether app.

● WIRELESS FEATURES

• Standards : Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz
• WiFi Speeds : AX6600 5 GHz: 4804 Mbps (802.11ax, HE160) 5 GHz: 1201 Mbps (802.11ax) 2.4 GHz: 574 Mbps (802.11ax)
• WiFi Range : 4 Bedroom Houses 8× Detachable High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range High-Power FEM Improves transmission power to strengthen signal coverage 4T4R Multiple streams in the same band strengthen the fault tolerance in transmission
• WiFi Capacity : Very High Tri-Band Allocate devices to different bands for optimal performance 4×4 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients OFDMA Simultaneously communicates with multiple Wi-Fi 6 clients Airtime Fairness Improves network efficiency by limiting excessive occupation DFS Access an extra band to reduce congestion 8 Streams Connect your devices to more bandwidth
• Working Modes : Router Mode Access Point Mode

● HARDWARE FEATURES

• Processor : 1.5 GHz Quad-Core CPU
• Ethernet Ports : 1× 2.5 Gbps WAN/LAN Port 1× Gigabit WAN/LAN Port 3× Gigabit LAN Ports
• USB Support : 1× USB 3.0 Port 1× USB 2.0 Port Supported Partition Formats: NTFS, exFAT, HFS+, FAT32 Supported Functions: Apple Time Machine FTP Server Media Server Samba Server
• Buttons : Wi-Fi On/Off Button Power On/Off Button LED On/Off Button WPS Button Reset Button
• Power : 12 V ⎓ 5 A

● SECURITY

• WiFi Encryption : WPA WPA2 WPA3 WPA/WPA2-Enterprise (802.1x)
• Network Security : SPI Firewall Access Control IP & MAC Binding Application Layer Gateway HomeCare™ Antivirus Malicious Site Checker Port Intrusion Prevention Infected Device Isolation Notification and Log
• Guest Network : 2× 5 GHz Guest Network 1× 2.4 GHz Guest Network
• VPN Server: OpenVPN PPTP

● SOFTWARE FEATURES

• Protocols : IPv4 IPv6
• Game Center : Game Accelerator Detects and optimizes gaming streams to keep latency as low as possible Game Statistics Check real-time latency, system utilization, and game duration on a redesigned dashboard to tweak every detail Game Protector Keep your accounts and system safe with HomeCare™ antivirus protection
• Service Kits : HomeCare™
• OneMesh™ : OneMesh™ Supported Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
• Parental Controls : HomeCare™ Parental Controls Custom Profiles Content Filtering App Block URL Filtering Time Limit Time Schedule (Bedtime) Log Insight
• WAN Types : Dynamic IP Static IP PPPoE PPTP L2TP
• Quality of Service : Game Accelerator QoS. QoS by Device HomeCare™ QoS QoS by Application
• Cloud Service : Auto Firmware Upgrade OTA Firmware Upgrade TP-Link ID DDNS
• NAT Forwarding : Port Forwarding Port Triggering DMZ UPnP
• IPTV : IGMP Proxy IGMP Snooping Bridge Tag VLAN
• DHCP : Address Reservation DHCP Client List Server
• DDNS : TP-Link NO-IP DynDNS
• Management : Tether App Webpage

●PHYSICAL

• Dimensions (W×D×H) : 8.3 × 8.3 × 2.0 in (212 × 212 × 51.8 mm)
• Package Contents : Wi-Fi Router Archer GX90 Power Adapter RJ45 Ethernet Cable Quick Installation Guide

● OTHER

• System Requirements : Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access)
• Certifications : FCC, CE, RoHS
• Environment : Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing

● TEST DATA

• WiFi Transmission Power : CE: <20dBm(2.4GHz) <23dBm(5.15GHz~5.35GHz) <30dBm(5.47GHz~5.725GHz) FCC: <30dBm(2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz) <24dBm(5.25GHz-5.35GHz & 5.47GHz-5.725 GHz)
