CPU | AMD Socket AM5, support for: – AMD Ryzen™ 9000 Series Processors – AMD Ryzen™ 8000 Series Processors – AMD Ryzen™ 7000 Series Processors Check GIGABYTE’s website for the latest CPU support list. |
Chipset | AMD B850 |
Memory | – Support for DDR5 8200(O.C) to 4400 MT/s memory modules – 4 x DDR5 DIMM sockets, up to 256 GB (64 GB single DIMM capacity) – Dual channel memory architecture – Non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 support – AMD EXPO™ & XMP memory modules support Refer to GIGABYTE’s website for the memory support list. |
Onboard Graphics | – Integrated AMD Radeon™ Graphics – 1 x DisplayPort (3840×2160@144 Hz, DP 1.4, HDR) – 1 x Front HDMI (1920×1080@30 Hz, HDMI 1.4) Graphics specifications depend on CPU support. |
Audio | – Realtek® Audio CODEC, High Definition Audio – 2/4/5.1/7.1-channel support (configurable via software) – S/PDIF Out support |
LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
Wireless | Realtek® Wi-Fi 7 RTL8922AE – 802.11a/b/g/n/ac/ax/be, 2.4/5/6 GHz bands – Bluetooth 5.4 Wi-Fi 7 requires Windows 11 SV3; no Windows 10 support. |
Expansion Slots | – 1 x PCI Express x16 (CPU-integrated): – Ryzen™ 9000/7000: PCIe 5.0 x16 – Ryzen™ 8000: PCIe 4.0 x8/x4 Supports graphics card or NVMe SSD. – Chipset: 2 x PCIe x1 slots (PCIe 4.0) |
Storage Interface | – 1 x M.2 (CPU-integrated, PCIe 5.0/4.0) – 1 x M.2 (CPU-integrated, PCIe 4.0) – 1 x M.2 (Chipset, PCIe 4.0) – 4 x SATA 6Gb/s connectors – RAID 0/1/5/10 support for NVMe & SATA RAID 5 is limited to Ryzen™ 9000. |
USB | CPU: – 1 x USB Type-C® (USB 3.2 Gen 2) – 2 x USB 3.2 Gen 2 Type-A – 4 x USB 2.0/1.1 Chipset: – 1 x USB Type-C® (USB 3.2 Gen 2×2) – 3 x USB 3.2 Gen 1 – 4 x USB 2.0/1.1 – 4 x USB 3.2 Gen 1 (via Hub) |
Internal I/O | – 1 x 24-pin ATX power connector – 1 x 8-pin + 1 x 4-pin ATX 12V power connectors – CPU, system, and water cooling headers – 3 x addressable RGB Gen2 headers, 1 x RGB LED header – M.2 and SATA connectors – Front panel headers, TPM header, HDMI port – Power, reset, and Clear CMOS jumpers |
Back Panel | – 1 x DisplayPort – 1 x Q-Flash Plus button – 4 x USB 2.0/1.1 – 1 x USB Type-C® (USB 3.2 Gen 2) – 5 x USB 3.2 Gen 1 – 2 x USB 3.2 Gen 2 Type-A – 1 x RJ-45 LAN – 2 x Antenna connectors – 2 x Audio jacks – 1 x Optical S/PDIF Out |
I/O Controller | iTE® I/O Controller Chip |
H/W Monitoring | – Voltage, temperature, and fan speed detection – Water cooling flow rate detection – Fan fail warning – Fan/pump speed control (varies by hardware installed) |
BIOS | – 1 x 256 Mbit flash, AMI UEFI BIOS – PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
Unique Features | – GIGABYTE Control Center (GCC) – Q-Flash and Q-Flash Plus – Smart Backup |
Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
Operating System | Support for Windows 11 64-bit |
Form Factor | ATX Form Factor (30.5cm x 24.4cm) |
Specification may change without further notice.
