LIAN LI chassis compatible list:
Top installation without issue
✔ O11D EVO RGB
✔ O11D EVO
✔ O11D EVO XL
✔ O11D
✔ O11DXL
✔ O11D MINI (3 slots mode)
Top installation with mounting the 3rd tube clamp to help tube organizing
(due to limited space between the motherboard and the fan)
✔ LANCOOL 216
✔ LANCOOL III
Side installation with tubes on the pump bottom oriented
Note: The AIO performance will not be as optimal.
✔ O11 Vision
Remove the L-shape cover and all the tube clamps to install
✔ SUP01
Not compatible
✘ O11D MINI (5&7 slots mode)
✘ O11 AIR MINI
✘ A3-mATX
✘ LANCOOL II
SPECIFICATIONS
MODEL NAME | HYDROSHIFT LCD 360 FAN-LESS | |
---|---|---|
MODEL NO. | GHSLCD36NB | GHSLCD36NW |
TYPE | 360 | |
COLOR | Black | White |
PUMP SPEED | 3800RPM (Max.) | |
WATER BLOCK DIMENSION | 72 x 72 x 59mm | |
WATER BLOCK TYPE | LCD DISPLAY TYPE: 2.88” IPS LCD DISPLAY RESOLUTION: 480 ×80 pixels SCREEN BRIGHTNESS: 500 nits |
|
RADIATOR DIMENSION | 403 x 124.5 x 27mm | |
RADIATOR MATERIAL | Aluminum | |
RADIATOR FINS | Single wave | |
TUBE LENGTH | 475mm | |
COMPATIBLE CPU SOCKETS | Intel: LGA 1700 AMD: AM5 / AM4 |
Specifications may change without further notice.
SKU: N/A
Categories: AIO Liquid Cooling System, Cooling Systems
