Fractal Design Meshify 2 XL Dark Tempered Glass ATX Chassis

Specifications

• 3.5″/2.5″ Universal drive mounts
  6 included, 18 positions total + 2 Multibrackets
• Dedicated 2.5″ drive mounts
  2 included, 5 positions total
• Expansion slots
  9 + 3
• Front interface
  1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button
• Total fan mounts
  11x 120 mm or 9x 140 mm
• Front fan
  4x 120 mm or 3x 140 mm, (2x Dynamic X2 GP-14 included)
• Top fan
  4x 120 mm or 3x 140 mm
• Rear fan
  1x 120/140 mm, (1x Dynamic X2 GP-14 included)
• Bottom fan
  2x 120/140 mm
• Dust filters
  Top, front and bottom
• Fixed velcro straps
  Yes
• Cable routing grommets
  Yes
• Captive thumbscrews
  HDD, SSD and PSU brackets
• Left side panel
  Tempered glass dark tint
• Right side panel
  Steel

Compatibility

• Motherboard compatibility
  E-ATX / ATX / mATX / Mini-ITX / EE-ATX / SSI-CEB / SSI-EEB
• Power supply type
  ATX
• PSU max length
  250 mm (both HDD cages installed)
• GPU max length
  Storage layout: 340 mm Open layout: 530 mm (505 mm w/ front fan)
• CPU cooler max height
  185 mm
• Front radiator
  Up to 480/420 mm
• Top radiator
  Up to 480/420 mm
• Rear radiator
  120 mm
• Bottom radiator
  Up to 240/280 mm
• Cable routing space
  30 mm

Dimensions

• Case dimensions (LxWxH)
  600 x 240 x 566 mm
• Case dimensions w/o feet/protrusions/screws
  588 x 240 x 547 mm
• Package dimensions (LxWxH)
  651 x 330 x 684 mm
• Net weight
  14.1 kg
• Gross weight
  16.4 kg
• Volume
  77,2 liters
