Attribute | TD500V2-KGNN-S00 | TD500V2-WGNN-S00 |
---|---|---|
Exterior Color | Black | White |
Materials – Exterior | Steel, Mesh, Plastic | Steel, Mesh, Plastic |
Materials – Left Side Panel | Tempered Glass | Tempered Glass |
Dimensions (L x W x H) | 499 x 210 x 500mm (incl. Protrusions), 430 x 210 x 477mm (excl. Protrusions) | 499 x 210 x 500mm (incl. Protrusions), 430 x 210 x 477mm (excl. Protrusions) |
Motherboard Support | Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX* (*up to 12″ x 10.7″ motherboards, may impact cable management feature) | Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX* (*up to 12″ x 10.7″ motherboards, may impact cable management feature) |
Expansion Slots | 7 | 7 |
3.5″ Drive Bays | 2 | 2 |
2.5″ Drive Bays | 3 | 3 |
I/O Panel – USB Ports | 2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 Type C | 2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 Type C |
I/O Panel – Audio In / Out | 1x Audio Jack | 1x Audio Jack |
I/O Panel – Other | 1x ARGB Fan Hub | 1x ARGB Fan Hub |
Pre-installed Fans – Front | 3x 120mm CF120 ARGB | 3x 120mm CF120 ARGB |
Pre-installed Fans – Rear | N/A | N/A |
Fan Support – Top | 3x 120mm, 2x 140mm | 3x 120mm, 2x 140mm |
Fan Support – Front | 3x 120mm, 2x 140mm | 3x 120mm, 2x 140mm |
Fan Support – Rear | 1x 120mm | 1x 120mm |
Radiator Support – Top | 120mm, 140mm, 240mm, 280mm, 360mm (recommended maximum thickness -55mm) | 120mm, 140mm, 240mm, 280mm, 360mm (recommended maximum thickness -55mm) |
Radiator Support – Front | 120mm, 140mm, 240mm, 280mm, 360mm | 120mm, 140mm, 240mm, 280mm, 360mm |
Radiator Support – Rear | 120mm | 120mm |
Clearance – CPU Cooler | 165mm/6.49″ | 165mm/6.49″ |
Clearance – PSU | 200mm (Recommended up to 170mm) | 200mm (Recommended up to 170mm) |
Clearance – GFX | 410mm / 16.14″ | 410mm / 16.14″ |
Cable Routing – Behind Motherboard Tray | 19mm / 0.74″ | 19mm / 0.74″ |
Dust Filters | Front, Top, Bottom | Front, Top, Bottom |
Power Supply Support | Bottom Mount, ATX | Bottom Mount, ATX |
Series | MasterBox Series | MasterBox Series |
Size | Mid Tower | Mid Tower |
Specification May change without further notice.
