Dahua DHI-ASI2212J | Single Door Password | ID Card | Fingerprint Access Standalone
Availability:
Onstock at Online Warehouse
- 2.4″ TFT display screen with a resolution of 240 × 320.
- Audio prompts.
- Supports 30,000 users, 30,000 cards, 30,000 passwords, 5,000 fingerprints, and 100,000 records.
- The security module expansion is supported to enhance security and protect against the device being opened during a power failure.
- Fingerprint/card/remote/password unlock and unlock through their combinations.
- Supports duress alarm, tamper alarm, intrusion alarm, door contact timeout alarm, illegal card exceeding threshold alarm, illegal password exceeding threshold alarm and external alarm.
- Supports guest users, patrol users, blocklist users, VIP users, general users, and others.
- TCP/IP and Wi-Fi communication; auto registration, P2P registration,
and DHCP. - Supports online update and USB update.
- Supports PoE to provide power to the access controller, and the access controller provides power to both a card reader (12 V 200 mA at most) and a electromagnetic lock (12 V, 500 mA at most)
₱37,050.00
6-Month Grace monthly payment:
₱3,735
12-Month Full Interest monthly payment:
₱4,381
Learn more about Billease Installment at Checkout
Estimated Delivery: Jun 6 - Jun 11, 2026 (Business Days)
Onstock at Online Warehouse
⚡ 24-Hour Shipping Eligible – In-Stock & Ready to Ship
Check items here that is part of our 99% Same-Day Shipping program displayed with 24 Hours Delivery Banner.
✔ Orders placed before 2:00 PM have the highest chance for same-day shipping or delivery.
✔ Orders after 2:00 PM may still be shipped the same day, but no guarantee.
✔ Applies to items labeled under our 24-hour delivery process.
❗ If your cart includes non-eligible items, your order will follow standard processing.
🚚 Nationwide Coverage:
Orders are shipped out within 24 hours across Luzon, Visayas, and Mindanao, depending on courier and location.
📦 Stock-Based System:
This badge appears only on selected product, showcasing our massive inventory selection ready to ship anytime anywhere.
💳 Payment Note: Fully paid orders are eligible for 24hrs Delivery on Selected Cities. COD orders will only be guaranteed shipped within 24 hours.
🕒 View All 24-Hour Eligible Products
Check items here that is part of our 99% Same-Day Shipping program displayed with 24 Hours Delivery Banner.
✔ Orders placed before 2:00 PM have the highest chance for same-day shipping or delivery.
✔ Orders after 2:00 PM may still be shipped the same day, but no guarantee.
✔ Applies to items labeled under our 24-hour delivery process.
❗ If your cart includes non-eligible items, your order will follow standard processing.
🚚 Nationwide Coverage:
Orders are shipped out within 24 hours across Luzon, Visayas, and Mindanao, depending on courier and location.
📦 Stock-Based System:
This badge appears only on selected product, showcasing our massive inventory selection ready to ship anytime anywhere.
💳 Payment Note: Fully paid orders are eligible for 24hrs Delivery on Selected Cities. COD orders will only be guaranteed shipped within 24 hours.
🕒 View All 24-Hour Eligible Products
| Main Processor | Embedded Processor |
| Button Type | Mechanical |
| Network Protocol | UDP; TCP; IPv4; P2P |
| OSDP Protocol | Yes |
| Interoperability | CGI; ONVIF |
| SDK and API | Yes |
| Product Type | Standalone |
| Display Screen | 2.4″ LCD |
| Screen Type | LCD |
| Screen Resolution | 240 (H) × 320 (V) |
| Voice Prompt | Yes |
| Backlight | Yes |
| Casing Material | PC+ABS |
| Verification Method | Configuration of card, remote, password, fingerprint combination unlock and multi-user combination unlock |
| Unlock Mode | Card, remote, password, fingerprint combination unlock and multi-user combination unlock |
| Card Type | Mifare cards (IC card) |
| Period List | 128 periods |
| Holiday Period | 128 periods |
| Network Update | Yes |
| First User Unlock | Yes |
| Remote Verification | Yes |
| Restricted List/Trusted List | Yes |
| Wi-Fi | Yes |
| Wireless Standard | IEEE802.11b/802.11g/802.11n |
| Wireless Frequency range | 2.4GHz |
| Peripheral Card Reader | 1 × RS-485 card reader<br>1 × Wiegand card reader |
| Multi-user Authentication | Yes |
| Multi-factor Authentication | Yes |
| Web Configuration | Yes |
| Auto Registration | Yes |
| Card Reading Distance | 0 cm–6 cm (0″–2.36″) |
| Fingerprint Sensor Type | Optical |
| Fingerprint Verification Mode | 1:N |
| Fingerprint Comparison Time | 1 s |
| User (Card) Type | Normal user; VIP users; patrol users; guest user; blocklist user; other user |
| User Capacity | 30,000 |
| Fingerprint Capacity | 5,000 |
| Card Capacity | 30,000 |
| Password Capacity | 30,000 |
| Record Capacity | 100,000 |
| Port | RS-485: 1<br>Wiegand: 1<br>USB: 1 × USB 2.0<br>Network Port: 1 × RJ-45 100 Mbps self-adaptive Ethernet port |
| Alarm Input | 2 |
| Alarm Output | 2 |
| Alarm Linkage | Yes |
| Doorbell | 1 |
| Exit Button | 1 |
| Door Status Detection | 1 |
| Lock Control | 1 |
| Alarm | Anti-pass Back: Yes<br>Tamper Alarm: Yes<br>Duress Alarm: Yes<br>Door Sensor Timeout: Yes<br>Intrusion: Yes<br>Illegal Card Exceeding Threshold: Yes<br>Duress Fingerprint: Yes |
