| Camera | |
|---|---|
| Pixel | 2 MP |
| Image Sensor | 2 MP CMOS |
| Max. Resolution | 1920 (H) × 1080 (V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25 s–1/100,000 s |
| NTSC: 1/30 s–1/100,000 s | |
| Min. Illumination | 0.001 lux@F1.6 (Color, 30 IRE) |
| 0.0001 lux@F1.6 (B/W, 30 IRE) | |
| 0 lux (Illuminator on) | |
| S/N Ratio | >65 dB |
| Illumination Distance | IR: 40 m (131.23 ft) |
| Warm light: 40 m (131.23 ft) | |
| Illuminator On/Off Control | Auto/Manual |
| Illuminator Number | 2 (IR light) |
| 2 (Warm light) | |
| Pan/Tilt/Rotation Range | Pan: 0°–360° |
| Tilt: 0°–78° | |
| Rotation: 0°–360° | |
| Lens | |
| Lens Type | Fixed-focal |
| Lens Mount | M12 |
| Focal Length | 2.8 mm |
| 3.6 mm | |
| Max. Aperture | F1.6 |
| Field of View | |
| 2.8 mm: H: 108°; V: 58°; D: 127° | |
| 3.6 mm: H: 86°; V: 46°; D: 101° | |
| Iris Control | Fixed |
| Close Focus Distance | 2.8 mm: 0.7 m (2.29 ft) |
| 3.6 mm: 1.1 m (3.61 ft) | |
| DORI Distance | |
| Lens | Detect |
| Observe | |
| Recognize | |
| Identify | |
| Video | |
| Video Frame Rate | CVI: PAL: 1080p@25 fps; |
| NTSC: 1080p@30 fps; | |
| AHD: PAL: 1080p@25 fps; | |
| NTSC: 1080p@30 fps; | |
| TVI: PAL: 1080p@25 fps; | |
| NTSC: 1080p@30 fps; | |
| CVBS: PAL: 960 × 576H; | |
| NTSC: 960 × 480H | |
| Resolution | 1080p (1920 × 1080); |
| 960H (960 × 576/960 × 480) | |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | BLC; HLC; WDR |
| WDR | 130 dB |
| White Balance | Auto; Area white balance |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D NR |
| Smart Illumination | Yes |
| Mirror | Off/On |
| Privacy Masking | Off/On (8 areas, rectangle) |
| Illuminator | Smart IR&WL; WL Mode; IR Mode |
| Active Deterrence | |
| Sound Warning | |
| Audio1: alarm | |
| Audio2: No parking here | |
| Audio3: Private land no entry. | |
| Audio4: Warning zone keep off. | |
| Audio5: Welcome | |
| Volume: high/medium/low; | duration: 5 s–60 s; 110 dB |
| Red/Blue Light Warning | Flash: 5 s–60 s; frequency: high/medium/low |
| Certification | |
| Certifications | CE, FCC, UL |
| Port | |
| Video Output | CVI/TVI/AHD/CVBS by one BNC port |
| Audio Input | One channel built-in MIC (-A) |
| Power | |
| Power Supply | 12 VDC ± 30% |
| Power Consumption | Max 7.6 W (12 VDC, IR on) |
| Environment | |
| Operating Temperature | –40 °C to +60 °C |
| Operating Humidity | <95% (RH), non-condensing |
| Storage Temperature | –40 °C to +60 °C |
| Protection | IP67 |
| Structure | |
| Casing Material | Inner core: Metal + plastic |
| Cover: Plastic | |
| Product Dimensions | Φ109.9 mm × 100.9 mm (Φ4.33″ × 3.97″) |
| Packaging Dimensions | 148 mm × 139 mm × 137 mm (5.83″ × 5.47″ × 5.39″) |
| Net Weight | 0.32 kg (0.71 lb) |
| Gross Weight | 0.50 kg (1.10 lb) |
| Installation | Wall mount; ceiling mount; vertical pole mount |
