Experience a superior and beautifully crafted frame on the NITRO+ AMD Radeon™ RX 7800 XT Graphics Card with an Aluminum Alloy Frame that fortifies the shroud structure and durability while encasing the sides of the PCB for a strong encasement alongside the All Metal Backplate.
Digital Power Design
SAPPHIRE NITRO+ AMD Radeon™ RX 7000 Series are designed with digital power which provides accurate power control and excellent power efficiency
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Tough Metal Backplate
The all-aluminum backplate provides additional rigidity that guarantees nothing bends and dust stays out. It also helps cool your card by increasing heat dissipation.
Dedicated VRM Cooling
Dedicated VRM cooling module to create optimal heat dissipation for peak airflow and cooling performance.
Component
Specification
GPU
AMD Radeon™ RX 7800 XT Graphics Card
Manufacturing Process
5nm
Architecture
AMD RDNA™ 3
Stream Processors
3840
Compute Units
60 CU (with RT+AI Accelerators)
Infinity Cache
64MB
Ray Accelerators
60
Memory Size/Bus
16GB/256 bit GDDR6
Maximum Displays Supported
4 Displays
Max Resolution (HDMI)
7680×4320
Max Resolution (DisplayPort)
7680×4320
Interface
PCI-Express 4.0 x16
Outputs
2x HDMI, 2x DisplayPort
BIOS Support
Dual UEFI
Game Index
4K
Sapphire Features
Dual BIOS
TriXX Software Switch
Premium Digital Power Design
Ultra High Performance Conductive Polymer Aluminum Capacitors
Fuse Protection
Tri-X Cooling Technology
High TG Copper PCB
Optimized Composite Heatpipe
Intelligent Fan Control
Precision Fan Control
Metal Backplate with ARGB
ARGB Light Bar
Two-Ball Bearing Fans
Angular Velocity Fan Blade
Assistive System Fan Control
Aluminum Alloy Frame
Dedicated VRM Cooling
Wave Fin Design
V Shape Fin Design for GPU Cooling
TriXX Supported
Fan Check
Fan Quick Connect
TriXX Boost
NITRO Glow
External RGB LED MB Synchronization
Accessories Bundled
Graphics Card Supporter
ARGB Extension Cable
AMD Features
AMD RDNA™ 3 Architecture
60 AMD RDNA™ 3 Compute Units
64MB AMD Infinity Cache™ Technology
DisplayPort™ 2.1 Support
AMD Radiance Display™ Engine
16GB GDDR6 on 256-Bit Memory Bus
PCI® Express 4.0 ready
AMD FidelityFX™ Super Resolution technology
Microsoft® DirectX® 12 Ultimate Support
Microsoft® DirectStorage Support
Vulkan® Optimized
AMD Smart Technologies
AMD Software: Adrenalin Edition™
AMD Noise Suppression
AMD Privacy View
AMD Radeon™ Super Resolution technology
AMD Link
AMD FreeSync™ Technology
Cooling
3 Fans
Form Factor
3 slot, ATX
Dimensions: 320(L)X 134.85(W)X 61.57 (H)mm
Power Consumption
288W Total Board Power
Supported Operating Systems
Linux®, Windows® 10, and Windows 11. 64-bit OS required
System Requirements
Minimum 700 Watt Power Supply
2 x 8-pin Power Connector
PCI Express® based PC with one X16 lane graphics slot
Sapphire NITRO+ AMD Radeon RX 7800 XT 16GB GDDR6 256 Bit Graphics Card
AMD Video Cards, Video Cards
BTZ Deals, Nvidia Video Cards, Video Cards
Nvidia Video Cards, Video Cards
Nvidia Video Cards, Video Cards
Nvidia Video Cards, Video Cards
Exceptional performance for its price.
Excellent customer service. The staff is helpful and always willing to provide assistance. Item was received without any issues.
