Intel Core Ultra 9 Processor 285K 36M Cache up to 5.70 GHz LGA 1851 Arrow Lake Desktop Processor

Intel
Availability:

Not Available. Check Counterpart Models. Thank you

Recently Sold: 1

  • Total Cores: 24
  • # of Performance-cores: 8
  • # of Efficient-cores: 16
  • Total Threads: 24
  • Max Turbo Frequency: 5.7 GHz
  • Intel® Thermal Velocity Boost Frequency: 5.7 GHz
  • Intel® Turbo Boost Max Technology 3.0 Frequency: 5.6 GHz
  • Performance-core Max Turbo Frequency: 5.5 GHz
  • Efficient-core Max Turbo Frequency: 4.6 GHz
  • Performance-core Base Frequency: 3.7 GHz
  • Efficient-core Base Frequency: 3.2 GHz
  • Cache: 36 MB Intel® Smart Cache
  • Total L2 Cache: 40 MB
  • Processor Base Power: 125 W
  • Maximum Turbo Power: 250 W
  • Intel® Deep Learning Boost (DL Boost) on CPU: Yes
  • AI Software Frameworks Supported: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
  • CPU Lithography: TSMC N3B

₱38,000.00

Not Available. Check Counterpart Models. Thank you

Frequently Bought Together

CPU Specifications
Total Cores 24
# of Performance-cores 8
# of Efficient-cores 16
Total Threads 24
Max Turbo Frequency 5.7 GHz
Intel® Thermal Velocity Boost Frequency 5.7 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency 5.6 GHz
Performance-core Max Turbo Frequency 5.5 GHz
Efficient-core Max Turbo Frequency 4.6 GHz
Performance-core Base Frequency 3.7 GHz
Efficient-core Base Frequency 3.2 GHz
Cache 36 MB Intel® Smart Cache
Total L2 Cache 40 MB
Processor Base Power 125 W
Maximum Turbo Power 250 W
Intel® Deep Learning Boost (DL Boost) on CPU Yes
AI Software Frameworks Supported by CPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
CPU Lithography TSMC N3B
Supplemental Information
Marketing Status Launched
Launch Date Q4’24
Embedded Options Available No
Use Conditions PC/Client/Tablet, Workstation
Memory Specifications
Max Memory Size 192 GB
Memory Types Up to DDR5 6400 MT/s
Maximum Memory Speed 6400 MHz
Max # of Memory Channels 2
ECC Memory Supported Yes
GPU Specifications
GPU Name Intel® Graphics
Graphics Base Frequency 300 MHz
Graphics Max Dynamic Frequency 2 GHz
GPU Peak TOPS (Int8) 8
Graphics Output DP2.1 UHBR20, HDMI 2.1 FRL 12GHz, eDP1.4b
Xe-cores 4
Max Resolution (HDMI) 4K @ 60Hz (HDMI 2.1 TMDS), 8K @ 60Hz (HDMI 2.1 FRL)
Max Resolution (DP) 8K @ 60Hz
Max Resolution (eDP) 4K @ 60Hz
DirectX* Support 12
OpenGL* Support 4.5
OpenCL* Support 3
Intel® Quick Sync Video Yes
# of Displays Supported 4
Intel® DL Boost on GPU Yes
NPU Specifications
NPU Name Intel® AI Boost
NPU Peak TOPS (Int8) 13
Sparsity Support Yes
Windows Studio Effects Support Yes
AI Software Frameworks Supported by NPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
Expansion Options
Direct Media Interface (DMI) Revision 4
Max # of DMI Lanes 8
Intel® Thunderbolt™ 4 Yes
Scalability 1S Only
PCI Express Revision 5.0 and 4.0
PCI Express Configurations Up to 1×16+2×4, 2×8+2×4, 1×8+4×4
Max # of PCI Express Lanes 24
Package Specifications
Sockets Supported FCLGA1851
Thermal Solution Specification PCG 2020A
Max Operating Temperature 105 °C
Advanced Technologies
Intel® Volume Management Device Yes
Intel® Gaussian & Neural Accelerator 3.5
Intel® Thread Director Yes
Intel® Speed Shift Technology Yes
Intel® Thermal Velocity Boost Yes
Intel® Turbo Boost Max Technology 3.0 Yes
Intel® Turbo Boost Technology 2.0
Intel® 64 Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1, SSE4.2, AVX2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Security & Reliability
Intel vPro® Eligibility Intel vPro® Enterprise, Intel vPro® Platform
Intel® Threat Detection Technology Yes
Intel® Active Management Technology Yes
Intel® Standard Manageability Yes
Intel® Remote Platform Erase Yes
Intel® One-Click Recovery Yes
Intel® Hardware Shield Yes
Intel® Control-Flow Enforcement Technology Yes
Intel® Total Memory Encryption Multi Key
Intel® AES New Instructions Yes
Secure Key Yes
Intel® Trusted Execution Technology Yes
Execute Disable Bit Yes
Intel® OS Guard Yes
Intel® Boot Guard Yes
Mode-based Execute Control (MBEC) Yes
Intel® Stable IT Platform Program (SIPP) Yes
Intel® Virtualization Technology with Redirect Protection Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel® VT-x with Extended Page Tables (EPT) Yes
Specification may change without further notice.
