AMD Ryzen 7 7700 3.8GHz Up to 5.3GHz Socket AM5 Processor 100-100000592BOX

4 reviews

Domestic or Local Stocks via Bermor Techzone

Recently Sold: 40

Platform: Desktop
Product Family: AMD Ryzen™ Processors
Product Line: AMD Ryzen™ 7 Processors
# of CPU Cores: 8
# of Threads: 16
Max. Boost Clock: Up to 5.3GHz
Base Clock: 3.8GHz
L1 Cache: 512KB
L2 Cache: 8MB
L3 Cache: 32MB
Default TDP: 65W
Processor Technology for CPU Cores: TSMC 5nm FinFET
Unlocked for Overclocking: Yes
CPU Socket: AM5
Thermal Solution (PIB):
Max. Operating Temperature (Tjmax): 95°C


Step by Step PC Builder Here!

Frequently Bought Together

Performance Features
Precision Boost 2
AMD Ryzen processors monitor the system’s energy consumption, temperatures, and other factors to automatically raise clock speeds, allowing applications to perform faster.
Precision Boost Overdrive
Precision Boost Overdrive technology takes advantage of your compatible motherboard’s design to boost clock speeds higher and for longer periods of time. It also allows you to overclock the processor at the touch of a button.
AMD EXPO Technology
The AMD Extended Profiles for Overclocking (AMD EXPO Technology) provides users with advanced profile settings for memory overclocking with supported modules.
AMD Ryzen Master Utility
Personalized Performance
The AMD Ryzen Master Utility provides you with multiple custom profiles to store CPU, GPU, and memory configurations. Use it to configure performance parameters for the active cores and adjust memory times. You can also optimize general performance or fine tune your favorite applications.
System Monitoring
Monitor your system in real-time using the AMD Ryzen Master Utility, which features a histogram of per-core clock rates and temperature, including average and peak readings.
Specification Value
Platform Desktop
Market Segment Enthusiast Desktop
Product Family AMD Ryzen™ Processors
Product Line AMD Ryzen™ 7 Processors
AMD PRO Technologies No
Consumer Use Yes
Regional Availability Global
Former Codename “Raphael AM5”
Architecture “Zen 4”
Number of CPU Cores 8
Multithreading (SMT) Yes
Number of Threads 16
Max. Boost Clock Up to 5.3GHz
Base Clock 3.8GHz
L1 Cache 512KB
L2 Cache 8MB
L3 Cache 32MB
Default TDP 65W
Processor Technology for CPU Cores TSMC 5nm FinFET
Processor Technology for I/O Die TSMC 6nm FinFET
CPU Compute Die (CCD) Size 71mm²
I/O Die (IOD) Size 122mm²
Package Die Count 2
Unlocked for Overclocking Yes
AMD EXPO™ Memory Overclocking Technology Yes
Precision Boost Overdrive Yes
Curve Optimizer Voltage Offsets Yes
AMD Ryzen™ Master Support Yes
CPU Socket AM5
Supporting Chipsets A620, X670E, X670, B650E, B650
CPU Boost Technology Precision Boost 2
Instruction Set x86-64
Supported Extensions AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Thermal Solution (PIB) AMD Wraith Prism
Max. Operating Temperature (Tjmax) 95°C
Launch Date 1/14/2023
OS Support Windows 11 – 64-Bit Edition<br>Windows 10 – 64-Bit Edition<br>RHEL x86 64-Bit<br>Ubuntu x86 64-Bit (*OS support will vary by manufacturer)
USB Type-C® Support Yes
Native USB 3.2 Gen 2 (10Gbps) Ports 4
Native USB 3.2 Gen 1 (5Gbps) Ports 0
Native USB 2.0 (480Mbps) Ports 1
Native SATA Ports 0
PCIe Express® Version PCIe® 5.0
Native PCIe® Lanes (Total/Usable) 28 / 24
Additional Usable PCIe Lanes from Motherboard AMD X670E: 12x Gen4<br>AMD X670: 12x Gen4<br>AMD B650E: 8x Gen4<br>AMD B650: 8x Gen4
NVMe Support Boot, RAID0, RAID1, RAID10
System Memory Type DDR5
Memory Channels 2
Max. Memory 128GB
System Memory Subtype UDIMM
Max Memory Speed 2x1R DDR5-5200<br>2x2R DDR5-5200<br>4x1R DDR5-3600<br>4x2R DDR5-3600
ECC Support Yes (Requires mobo support)
Graphics Capabilities
Integrated Graphics Yes
Graphics Model AMD Radeon™ Graphics
Graphics Core Count 2
Graphics Frequency 2200 MHz
USB Type-C® DisplayPort™ Alternate Mode Yes
Product IDs
Product ID Boxed 100-100000592BOX
Product ID Tray 100-000000592
Key Features
Supported Technologies AMD EXPO™ Technology<br>AMD Ryzen™ Technologies
