Feature | Description |
---|---|
Unique Feature | Dual Channel DDR5 |
6+1 Power Phase | |
ASRock Auto Driver Installer (EZ Update) | |
Superb Productivity | Supports 13th Gen & 12th Gen Intel Core Processors |
Supports Intel Hybrid Technology | |
Supports Intel Turbo Boost Max 3.0 Technology | |
Chipset | Intel H610 |
Memory | Dual Channel DDR5 Memory Technology |
2 x DDR5 DIMM Slots | |
Max. capacity of system memory: 96GB | |
Supports Intel Extreme Memory Profile (XMP) 3.0 | |
BIOS | 128Mb AMI UEFI Legal BIOS with GUI support |
Graphics | Intel Xe Graphics Architecture (Gen 12) |
1 x HDMI 2.1 (4K 60Hz) | |
1 x DisplayPort 1.4 (8K 60Hz / 5K 120Hz) | |
1 x D-Sub (Full HD 60Hz) | |
Audio | 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
LAN | Gigabit LAN 10/100/1000 Mb/s (Realtek 8111H) |
Expansion Slots | CPU: 1 x PCIe 4.0 x16 Slot (Supports NVMe SSD) |
Chipset: 1 x PCIe 3.0 x1 Slot (Supports NVMe SSD) | |
Storage | Chipset: 1 x Ultra M.2 Socket (Supports NVMe SSD) |
4 x SATA3 6.0 Gb/s Connectors | |
USB Ports | 1 x USB 3.2 Gen1 Type-C (Rear) |
3 x USB 3.2 Gen1 Type-A (1 Rear, 2 Front) | |
6 x USB 2.0 (4 Rear, 2 Front) | |
Connectors | 1 x SPI TPM Header |
1 x Chassis Intrusion and Speaker Header | |
1 x Addressable LED Header (Supports 5V/3A LED) | |
1 x CPU Fan Connector (4-pin) | |
1 x Chassis/Water Pump Fan Connector (4-pin) | |
1 x 24 pin ATX Power Connector | |
1 x 8 pin 12V Power Connector | |
1 x Front Panel Audio Connector | |
1 x USB 2.0 Header (Supports 2 USB 2.0 ports) | |
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1) | |
Rear Panel I/O | 1 x PS/2 Mouse/Keyboard Port |
1 x D-Sub Port | |
1 x HDMI Port | |
1 x DisplayPort 1.4 | |
1 x USB 3.2 Gen1 Type-C Port | |
1 x USB 3.2 Gen1 Type-A Port | |
4 x USB 2.0 Ports | |
1 x RJ-45 LAN Port | |
HD Audio Jacks: Line in / Front Speaker / Mic | |
Software and UEFI | ASRock Motherboard Utility (A-Tuning) |
ASRock XFast LAN | |
ASRock Polychrome SYNC* | |
ASRock EZ Mode | |
ASRock Full HD UEFI | |
ASRock My Favorites in UEFI | |
ASRock Auto Driver Installer | |
ASRock Instant Flash | |
Accessories | 1 x User Manual |
1 x I/O Shield | |
2 x SATA Data Cables | |
1 x Screw for M.2 Socket | |
Form Factor | Micro ATX Form Factor (8.66-in x 7.6-in) |
OS | Microsoft Windows 10 64-bit / 11 64-bit |
Certifications | FCC, CE |
ErP/EuP ready (ErP/EuP ready power supply needed) |
Specification may change without further notice.
