X marks the next generation! Introducing the AORUS Z790 X Gen Motherboards, the most powerful platforms ever built for the next generation of Intel® Core™ processors. With the leading performance in DDR5 memory, the upgraded DIY-friendly innovations, and the all-new BIOS redesigned as user-centered, the AORUS Z790 X Gen Motherboards are built to fully unleash the next-gen power.
Component | Specification |
---|---|
CPU | Support for 13th and 12th Gen Intel Core, Pentium Gold, and Celeron Processors |
LGA1700 socket | Yes |
Chipset | Intel Z790 Express Chipset |
Memory | DDR5 8266(O.C) / 8200(O.C) / 8000(O.C) / … up to 192 GB, ECC and XMP support |
Onboard Graphics | Intel HD Graphics with various outputs |
Audio | Realtek ALC1220-VB CODEC, High Definition Audio, S/PDIF Out |
LAN | Realtek 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) |
Wireless Communication module | MediaTek Wi-Fi 7 MT7927 or Intel Wi-Fi 7 BE200 (depending on PCB revision) |
Expansion Slots | 1 x PCIe 5.0 x16 (CPU), 1 x PCIe 4.0 x16 (Chipset), 1 x PCIe 3.0 x16 (Chipset) |
Storage Interface | M.2 and SATA connectors, RAID support |
USB | Various USB ports including USB 3.2 Gen 2×2, USB Type-C |
Internal I/O Connectors | Various connectors for power, fans, RGB, USB, etc. |
Back Panel Connectors | USB, DisplayPort, HDMI, LAN, audio, etc. |
I/O Controller | iTE I/O Controller Chip |
H/W Monitoring | Voltage, temperature, fan speed, water cooling flow rate, fan fail warning, noise detection |
BIOS | AMI UEFI BIOS |
Unique Features | GIGABYTE Control Center, Q-Flash, Q-Flash Plus, Smart Backup |
Bundled Software | Norton Internet Security (OEM version), LAN bandwidth management software |
Operating System | Windows 11 64-bit |
Form Factor | ATX (30.5cm x 24.4cm) |
Specification may change without further notice.
