Asus ROG Strix B650E-I Gaming WIFI AMD Ryzen 7000 Series AM5 Motherboard - AMD Motherboards
Asus ROG Strix B650E-I Gaming WIFI AMD Ryzen 7000 Series AM5 Motherboard - AMD Motherboards
Asus ROG Strix B650E-I Gaming WIFI AMD Ryzen 7000 Series AM5 Motherboard - AMD Motherboards
Asus ROG Strix B650E-I Gaming WIFI AMD Ryzen 7000 Series AM5 Motherboard - AMD Motherboards
,

Asus ROG Strix B650E-I Gaming WIFI AMD Ryzen 7000 Series AM5 Motherboard

1 review
Availability:

Inquire First Before Checkout. Limited Stock or Overseas Stock

Recently Sold: 4

  • AM5
  • AMD Ryzen™ 7000 Series
  • AMD B650
  • 2 x DIMM, Max.64GB, DDR5
  • 1 x M.2 2242/2260/2280 (PCIe 5.0 x4)
    1 x M.2 2242/2260/2280 (PCIe 4.0 x4)
  • 1 x USB 3.2 Gen 2×2
    6 x USB 3.2 Gen 2
    2 x USB 3.2 Gen 1
    4 x USB 2.0
  • 2 x SATA 6Gb/s cables
    1 x Thermal pad for M.2
  • Wi-Fi 6E
  • 1 x Intel® 2.5Gb
  • Dynamic OC Switcher, PBO, Core Flex
  • Mini-ITX

₱18,995.00 ₱23,000.00

Inquire First Before Checkout. Limited Stock or Overseas Stock

Step by Step PC Builder Here!
Component Specification
CPU AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors*
Chipset AMD B650
Memory 2 x DIMM, Max. 96GB, DDR5 8000+(OC)/7800(OC)/7600(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000/4800 ECC and Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports AMD EXTended Profiles for Overclocking (EXPO™)
OptiMem II
Graphics 1 x HDMI® port***
1 x USB3.2 Gen2 port supports USB Type-C® display outputs****
Expansion Slots 1 x PCIe 5.0 x16 slot*
Storage Total supports 2 x M.2 slots and 2 x SATA 6Gb/s ports*
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
2 x SATA 6Gb/s ports
Ethernet 1 x Intel® 2.5Gb Ethernet
ASUS LANGuard
Wireless & Bluetooth Wi-Fi 6E
2×2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Bluetooth® v5.2**
USB Rear USB (Total 8 ports)
1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®)
5 x USB 3.2 Gen 2 ports (4 x Type-A + 1 x USB Type-C®)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 5 ports)
1 x USB 3.2 Gen 2 connector
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports
Audio ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
Impedance sense for front and rear headphone outputs
Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
Supports up to 32-Bit/384 kHz playback
Back Panel I/O Ports 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®)
5 x USB 3.2 Gen 2 ports (4 x Type-A + 1 x USB Type-C® with DP Alt mode)
2 x USB 2.0 ports (2 x Type-A)
1 x HDMI® port
1 x Wi-Fi Module
1 x Intel® 2.5Gb Ethernet port
3 x LED-illuminated audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack™ button
1 x FlexKey button
Internal I/O Connectors Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin AIO Pump header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
2 x M.2 slots (Key M)
2 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 2 connector
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 headers supports additional 2 USB 2.0 ports
Miscellaneous 1 x Addressable Gen 2 header
1 x AURA RGB header
1 x Clear CMOS header
1 x CPU Over Voltage jumper
1 x 12-1 pin Front Panel Audio header (AAFP)
1 x 10-1 pin System Panel header
1 x Speaker header
1 x Thermal Sensor header
Special Features Extreme Engine Digi+
ASUS Q-Design
ASUS Thermal Solution
ASUS EZ DIY
AURA Sync
Software Features ROG Exclusive Software
ASUS Exclusive Software
UEFI BIOS
Manageability WOL by PME, PXE
Accessories Cables
Additional Cooling Kit
Miscellaneous
Documentation
Operating System Windows® 11 64-bit, Windows 10 64-bit
Form Factor Mini-ITX Form Factor
6.7 inch x 6.7 inch (17 cm x 17 cm)

Specs may change anytime without further notice*
