| Compatibility | |
| Intel | 1700 |
| AMD | AM5, AM4 |
| PI | NNPI |
| TIM | MX-6 (0.8 g) |
| Operating Ambient Temperature | 0—40 °C |
| Weight | 2325 g |
| LED Connector | 3-Pin A-RGB Connector |
| All-In-One Connector | 4-Pin PWM Connector |
| Splitt Connector | 3x 4-Pin PWM Connector |
| Pump | |
| Pump Speed | 800—2800 rpm (PWM controlled) |
| Current | Voltage |
| Cold Plate | Copper, Micro Skived Fins |
| Tube Length | 450 mm |
| Tube Diameter | Outer: 12.4 mm Inner: 6.0 mm |
| Radiator | |
| Material | Aluminium |
| Dimensions | 458 (L) x 138 (W) x 38 (H) mm |
| VRM Module | |
| VRM Fan Speed | 400—2500 rpm (PWM controlled) |
| Current | Voltage |
| LEDs | 12x A-RGB LEDs |
| Current | Voltage |
| Radiator Fans | |
| Fan | 3x P14 PWM PST A-RGB |
| Speed | 200—1900 rpm |
| Air Flow | 69.90 cfm | 117.06 m3/h |
| Static Pressure | 2.0 mmH2O |
| Bearing | Fluid Dynamic Bearing |
| Current | Voltage |
| Cable Length | 40 mm |
| Connector | 4-Pin PWM Connector |
| RGB | |
| LEDs | 12x A-RGB LEDs |
| Current | Voltage |
| Cable Length | 40 mm + 80 mm Splitter Cable |
| Connector | 3-Pin A-RGB Connector + 3-Pin Plug |
Specification may change without further notice.
