ATX Version | ATX 12V Ver. 3.1 |
PFC | Active PFC |
Input Voltage | 100-240V |
Input Current | 10-6A |
Input Frequency | 50-60Hz |
Dimensions (L x W x H) | 140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch |
Fan Size | 120mm |
Fan Bearing | HDB |
Efficiency | >85% @ Typical Load |
80 PLUS Rating | 80 PLUS Bronze |
ErP 2014 Lot 3 | Yes |
Operating Temperature | 0-40°C |
Power Good Signal | 100 – 150 ms |
Hold Up Time | >16ms |
MTBF | >100,000 Hours |
Protections | UVP / OVP / OPP / OTP / SCP |
Regulatory | cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region’s requests.) |
ATX 24 Pin Connectors | 1 |
EPS 8 Pin / 4+4 Pin Connectors | 2 |
SATA Connectors | 6 |
Peripheral 4 Pin Connectors | 3 |
PCI-e 6+2 Pin Connectors | 4 |
Warranty | 5 Years |
Series | MWE Bronze Series |
Category | 500 to 750W |
Modular | Non Modular |
80 Plus Efficiency | Bronze |
Form Factor | ATX |
Watts | 750W |
Specification may change without further notice.
SKU: MPE-7501-ACABW-3BUS
