MSI MAG B650M Mortar WIFI AMD Ryzen 7000 Series AM5 Motherboard

1 review
Availability:

Domestic or Local Stocks via Bermor Techzone


Recently Sold: 11

  • Supports AMD Ryzen™ 7000 Series Desktop Processors
  • Supports DDR5 Memory, up to 6400+(OC) MHz
  • Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
  • 2.5G LAN and Intel Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
  • Lightning M.2: Running at PCIe Gen 4 maximizes performance for NVMe based SSDs
  • Lightning USB 20G: Built-in USB 3.2 Gen 2×2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1
  • AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience

12,495.00 15,000.00

Domestic or Local Stocks via Bermor Techzone

Step by Step PC Builder Here!
Estimated delivery dates: Mar 27, 2024 - Mar 30, 2024
Component Specification
CHIPSET AMD B650
CPU SUPPORT Supports AMD Ryzen™ 7000 Series Desktop Processors<br>Socket AM5
MEMORY 4x DDR5, Maximum Memory Capacity 192GB
Memory Support DDR5 7600+(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz<br>Max. overclocking frequency:<br>• 1DPC 1R Max speed up to 7600+ MHz<br>• 1DPC 2R Max speed up to 6400+ MHz<br>• 2DPC 1R Max speed up to 6400+ MHz<br>• 2DPC 2R Max speed up to 5400+ MHz
ONBOARD GRAPHICS 1x HDMI™<br>Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz*<br>1x DisplayPort<br>Support DP 1.4, maximum resolution of 8K 60Hz*<br>*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
EXPANSION SLOT 2x PCI-E x16 slot<br>Supports x16/x4<br>1x PCI-E x1 slot<br>PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)<br>PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)<br>PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
STORAGE 2x M.2<br>M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices<br>M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices<br>6x SATA 6G
RAID Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices*<br>Supports RAID 0 and RAID 1 for M.2 NVMe storage devices<br>* SATA_A1_A2 do not support RAID function.
USB 4x USB 2.0 (Front)<br>4x USB 3.2 Gen1 Type A (Rear)<br>2x USB 3.2 Gen1 Type A (Front)<br>3x USB 3.2 Gen2 Type A (Rear)<br>1x USB 3.2 Gen2 Type C (Front)<br>1x USB 3.2 Gen2x2 Type C (Rear)
LAN Realtek® RTL8125B 2.5Gbps LAN
WIRELESS / BLUETOOTH AMD Wi-Fi 6E<br>The Wireless module is pre-installed in the M.2 (Key-E) slot<br>Supports MU-MIMO TX/RX<br>Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands<br>Supports 802.11 a/ b/ g/ n/ ac/ ax<br>* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11.<br>** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
AUDIO Realtek® ALC4080 Codec<br>7.1-Channel High Performance Audio<br>Supports S/PDIF output<br>Supports up to 32-Bit/384 kHz playback on front panel
INTERNAL I/O 1x Power Connector(ATX_PWR)<br>2x Power Connector(CPU_PWR)<br>1x CPU Fan<br>1x Pump Fan<br>3x System Fan<br>2x Front Panel (JFP)<br>1x Chassis Intrusion (JCI)<br>1x Front Audio (JAUD)<br>1x Tuning Controller connector(JDASH)<br>2x Addressable V2 RGB LED connector (JARGB_V2)<br>2x RGB LED connector(JRGB)<br>1x TPM pin header(Support TPM 2.0)<br>4x USB 2.0 ports<br>2x USB 3.2 Gen1 Type A ports<br>1x USB 3.2 Gen2 Type C ports
LED FEATURE 4x EZ Debug LED
BACK PANEL PORTS DisplayPort 1.4<br>2.5G LAN Port<br>USB 3.2 Gen 2 10Gbps Type-A<br>USB 3.2 Gen 1 5Gbps Type-A<br>Wi-Fi / Bluetooth Antenna<br>HD Audio Connectors<br>Flash BIOS Button<br>HDMI™ 2.1 Port<br>USB 3.2 Gen 2×2 20Gbps Type-C<br>Optical S/PDIF OUT
OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
PCB DIMENSION (W × L) mATX<br>243.84mmx243.84mm

Specs may change anytime without further notice*
