| Size | 140 x 140 x 25 mm |
| Screw Hole Pattern | 125 x 125 mm |
| LED Type | Addressable RGB |
| Power Connector | 4-pin |
| Bearing | Rifle |
| Number of Blades | 7 |
| Rotational Speed | 500-1700 RPM |
| Noise Level | <10 – 35.5 dB(A) |
| Max Airflow (CFM) | 20 – 78 CFM |
| Max Airflow (m³/h) | 34 – 132.5 m³/h |
| Max Pressure | 0.30 – 2.05 mm H2O |
| Fan Typical Input Power | 2.16 W |
| Fan Max Input Current | 0.24 A |
| Fan Input Voltage | 12 V |
| Minimum Startup Voltage | 7 V |
| LED Rated Voltage | 5 V |
| LED Rated Current | 0.3 A |
| LED Rated Input Power | 1.5 W |
| MTTF | 90,000 h |
| Unit Weight | 155 g |
| Cable Length | 500 mm |
| Cable Type | Black/White ribbon (allows chaining) |
Specification may change without further notice.
SKU: FD-F-AS1-1405
Categories: Cooling Systems, Fans/Hubs/Controller
