Arctic P14 Pro 140mm PWM Single Fan – Black ACFAN00313A

ARCTIC P14 Pro

The ARCTIC P14 Pro is a high-performance 140 mm PWM fan designed for users who demand efficient cooling, strong static pressure, and quiet operation. Engineered for both radiator and case applications, it excels in airflow-restricted environments such as dense radiators, mesh intakes, dust filters, or compact PC builds. Its optimized blade design, durable bearing system, and intelligent motor control make it a reliable and versatile cooling solution for modern PC systems.

Performance & Airflow

The P14 Pro offers exceptional cooling performance thanks to its wide PWM-controlled speed range of 400–2500 rpm. At low speeds, it operates quietly for everyday use, while at maximum speed it delivers powerful cooling for high-demand scenarios.

• High Airflow: Capable of pushing up to 110 cfm (≈ 186 m³/h), the fan ensures rapid heat dissipation even when dealing with warm internal case temperatures.
• Strong Static Pressure: With 5.2 mmH₂O, the fan maintains efficient airflow through obstructions such as radiators, dust filters, or perforated panels.
• 0-RPM Mode: Below 5% PWM, the fan can stop completely, allowing for silent operation during low-load conditions.

These performance characteristics make the P14 Pro particularly effective for radiator cooling, restricted airflow areas, or performance-oriented gaming builds.

Design & Build Quality

The P14 Pro features a range of engineering enhancements that improve durability, acoustic performance, and operational smoothness:

• Fluid Dynamic Bearing (FDB): The extended-shaft FDB provides long-term reliability, lower friction, and reduced vibration compared to conventional bearings.
• Optimized Blade & Housing Geometry: Carefully tuned blade angles and frame structure help minimize turbulence while maximizing both airflow and static pressure.
• Precision Two-Plane Balancing: The fan undergoes a precise, automated balancing process to ensure smooth rotation and reduced vibration during operation.
• Smart Motor Control: An integrated controller reduces motor noise, stabilizes performance under load fluctuations, and protects against inrush current or reverse polarity.

Together, these design features ensure long-lasting, stable, and quiet performance.

Practical Details & Usability

The fan includes several thoughtful features for easy integration into modern PC systems:

• Connector: Standard 4-pin PWM connector for accurate speed control via motherboard or fan hub.
• Cable Length: 400 mm, providing generous reach for flexible mounting configurations.
• Operating Temperature: Suitable for environments ranging from 0 to 40 °C.
• Dimensions: Standard 140 × 140 × 27 mm size ensures broad compatibility with cases and radiators.
• Net Weight: Approximately 240 g, offering a solid, durable build without unnecessary bulk.
• Warranty: A long 6-year warranty, reflecting ARCTIC’s confidence in its longevity and performance.

Ideal Use Cases

The ARCTIC P14 Pro is an excellent choice for:

• Radiator cooling on AIOs or custom loops, thanks to its high static pressure.
• Mesh-filtered intake or exhaust configurations where airflow resistance is high.
• Silent PC builds, as it can maintain solid airflow at lower, quieter RPMs.
• Compact or airflow-restricted cases that require strong and directed airflow.
• High-performance gaming PCs or workstations where thermal efficiency is critical.
