Chassis
Cooler Master Elite 690 Wood ATX Panoramic Tempered Glass Case – Black | White
Availability:
Onstock at Online Warehouse
-
Real wood front panel accent adds warmth and texture to a minimalist build.
-
270° tempered glass panels provide full hardware visibility.
-
Vertical airflow layout with top-to-bottom mesh intake for optimal cooling.
-
Supports up to 10 fans and multiple radiator configurations.
-
Spacious interior fits GPUs up to 425mm and CPU coolers up to 170mm.
-
Compatible with ATX motherboards for flexible builds.
Price range: ₱4,195.00 through ₱4,295.00
6-Month Grace monthly payment:
₱423
12-Month Full Interest monthly payment:
₱496
Learn more about Billease Installment at Checkout
Estimated Delivery: Jun 13 - Jun 18, 2026 (Business Days)
Want to be Notified upon Restock
We will inform you when the product toggled in stock. Please leave your valid email address below.
⚡ 24-Hour Shipping Eligible – In-Stock & Ready to Ship
Check items here that is part of our 99% Same-Day Shipping program displayed with 24 Hours Delivery Banner.
✔ Orders placed before 2:00 PM have the highest chance for same-day shipping or delivery.
✔ Orders after 2:00 PM may still be shipped the same day, but no guarantee.
✔ Applies to items labeled under our 24-hour delivery process.
❗ If your cart includes non-eligible items, your order will follow standard processing.
🚚 Nationwide Coverage:
Orders are shipped out within 24 hours across Luzon, Visayas, and Mindanao, depending on courier and location.
📦 Stock-Based System:
This badge appears only on selected product, showcasing our massive inventory selection ready to ship anytime anywhere.
💳 Payment Note: Fully paid orders are eligible for 24hrs Delivery on Selected Cities. COD orders will only be guaranteed shipped within 24 hours.
🕒 View All 24-Hour Eligible Products
Check items here that is part of our 99% Same-Day Shipping program displayed with 24 Hours Delivery Banner.
✔ Orders placed before 2:00 PM have the highest chance for same-day shipping or delivery.
✔ Orders after 2:00 PM may still be shipped the same day, but no guarantee.
✔ Applies to items labeled under our 24-hour delivery process.
❗ If your cart includes non-eligible items, your order will follow standard processing.
🚚 Nationwide Coverage:
Orders are shipped out within 24 hours across Luzon, Visayas, and Mindanao, depending on courier and location.
📦 Stock-Based System:
This badge appears only on selected product, showcasing our massive inventory selection ready to ship anytime anywhere.
💳 Payment Note: Fully paid orders are eligible for 24hrs Delivery on Selected Cities. COD orders will only be guaranteed shipped within 24 hours.
🕒 View All 24-Hour Eligible Products
| Model Number | Black: E690-KHNN-S00, White: E690-WHNN-S00 |
| Color(s) | Black / White |
| Front Panel Material | Tempered Glass + Wood |
| Left Side Panel | Tempered Glass |
| Right Side Panel | Steel |
| Dimensions (L x W x H) | 434 x 218 x 454 mm (Incl. Protrusions) 430 x 218 x 435 mm (Excl. Protrusions) |
| Volume | 42.93 L (Incl. Protrusions) |
| Motherboard Support | ITX / Micro-ATX / ATX |
| Expansion Slots | 7 |
| 5.25″ Drive Bays | 0 |
| 3.5″ Drive Bays | 1 (Max. 2) |
| 2.5″ Drive Bays | 1 (Max. 2) |
| I/O Panel – USB Ports | 1 x USB Type-C 20Gbps, 2 x USB 3.0 |
| I/O Panel – Audio | 1 x 3.5mm Combo |
| Pre-installed Fans (Rear) | 1 x 120mm ARGB PWM |
| Pre-installed Fans (Side) | 2 x 120mm ARGB PWM Reverse Fan |
| Fan Support – Top | 2 x 140mm / 3 x 120mm |
| Fan Support – Rear | 1 x 120mm |
| Fan Support – Side | 2 x 120mm |
| Fan Support – Bottom | 3 x 120mm |
| Radiator Support – Top | 120 / 240 / 360mm (Max Height 45mm) |
| Radiator Support – Bottom | 120 / 240 / 360mm |
| Radiator Support – Side | 120 / 240mm |
| CPU Cooler Clearance | 170mm |
| PSU Clearance | 250mm |
| Graphics Card Clearance | 425mm |
| Power Supply Support | ATX |
| Size | Mid Tower |
| Series | Elite Series |
| Brands | |
|---|---|
| Color | Black, White |
| Chassis Size | ATX Midtower |
| Form Factor | ATX |
