Category | Specification |
---|---|
Camera | |
Image Sensor | 1/2.8” Progressive Scan CMOS |
Shutter Speed | 1/3 to 1/10000 s |
Slow Shutter | Yes |
Minimum Illumination | 0.005 Lux; 0 Lux with IR/White Light |
Day/Night Mechanism | IR Cut Filter |
Day/Night Switch | Unified / Scheduled / Auto |
Lens | |
Type | Fixed Focal Lens |
Focal Length | 2.8 / 4 / 6 mm |
Aperture | F1.6 |
FOV (2.8 mm) | H: 107.5°, V: 57.2°, D: 128.7° |
FOV (4 mm) | H: 84.4°, V: 44.3°, D: 100.6° |
FOV (6 mm) | H: 55.1°, V: 30.2°, D: 64° |
Lens Mount | M12 |
DORI (2.8 mm) | D: 52m, O: 22m, R: 10m, I: 5m |
DORI (4 mm) | D: 70m, O: 29m, R: 14m, I: 7m |
DORI (6 mm) | D: 100m, O: 41m, R: 20m, I: 10m |
Angle Adjustment (Manual) | Pan: 0-360°, Tilt: 0-90°, Rotation: 0-360° |
Illuminator | |
IR LED | 2 pcs, 30m range, 850nm |
White LED | 2 pcs, 30m range |
Control | Auto / Scheduled / Always on / Always off |
Video | |
Max. Resolution | 2304 × 1296 |
Main Stream | Up to 25fps @ 2304×1296 |
Sub-Stream | Up to 25fps @ 704×576 |
Bit Rate Control | CBR / VBR |
Compression | H.265+/H.265/H.264+/H.264 |
Video Bit Rate | Main: 256 Kbps–4 Mbps, Sub: 64 Kbps–512 Kbps |
Image | |
Settings | Brightness, Contrast, Saturation, WDR, Rotation, etc. |
Enhancement | BLC, 3D DNR, HLC, SmartIR |
WDR | DWDR |
SNR | ≥ 52 dB |
Privacy Mask | Up to 4 zones |
ROI | 1 region |
OSD | Yes |
Audio | |
Audio Input | Yes |
Compression | G.711 alaw, 64 Kbps |
Sampling Rate | 8 KHz |
Noise Filtering | Yes |
Network | |
Protocols | TCP/IP, UDP, HTTP(S), RTSP, NTP, FTP/SFTP, etc. |
ONVIF | Yes (Profile S) |
Live View | 3 Main + 3 Sub-streams |
Browser Support | Chrome, Firefox, Safari, Edge |
Cloud | Yes |
Security | Password, HTTPS, IP Filter, Digest Auth |
Alarm & Events | |
Smart Detection | Human, Vehicle, Intrusion, Loitering, etc. |
Basic Events | Motion, Tampering, Illegal Login |
Alarm Linkage | White Light Flash, Message Push |
Interfaces | |
Network | 1× RJ45 10/100M Ethernet, PoE |
Audio | Built-in Mic (5m radius) |
Reset | N/A |
Power Port | DC Input |
Storage | N/A |
General | |
Operating Temp | -30 to 60 °C |
Storage Temp | -40 to 60 °C |
Humidity | < 95% RH |
Power Supply | 12V DC / PoE (802.3af/at), Max. 6W |
Material | Plastic |
Dimensions (L×W×H) | 78.5 × 188.0 × 71.5 mm |
Weight | Net: 0.32 kg, Gross: 0.48 kg |
Protection | IP67 Waterproof |
Certifications | CE, NTRA, VCCI, BSMI |
Package Content | Camera, Guide, Mount Kit, Waterproof Accessories |
